INFUprim™ Infusion sets
- Intravenous therapy
Simple, intelligent solutions for each application of the infusion therapy, subject to the highest standards which guarantees SAFETY FOR PATIENTS, SAFETY FOR PHYSICIANS AND SAFETY FOR THE ENVIRONMENT. Our close cooperation with medical personnel helps us to develop new products for a variety of clinical applications. Our sales engineers will share their experience and help you choose the right solution for each infusion therapy need.
The IV administration set delivers fluid or medication from an infusate container (glass containers, flexible plastic containers, semi-rigid plastic containers) into the patient’s vascular system.
Standard infusion sets
For flexible plastic containers
For glass conta iners with solid rubber stopper and semirigid plastic containers
Air inlet with antibacterial filter and closing cap
Keeps internal pressure of IV set balanced with the atmospheric pressure. Built-in bacterial filter protects the infusion solution from contamination. Only for use with vacuum IV systems.
The drop factor is clearly stated on the administration set package. Extended drip element provides evidence for even drop formation.
Macrodrip tubing is made to deliver 20 drops/ml
Macrodrip tubing is made to deliver 60 drops/ml
Ergonomic design for fine and comfortable flow rate adjustment. Big screw ensures one hand operation.
Drum flow regulator
Accurate and stable flow rate delivery. Dial with graduation in ml/h with a wide scope (2 to 250 ml/h). Flow rate accuracy ± 5% to 10%.
Needle-free injection site
Needle-free injection site effectively reduces the risk of needlestick injury and infection to medical personnel.
Slide clamp for short-term interruption of infusion.
Latex “Y” injection site
Sealed with a non-removable rubber septum. The septum enables additional administration of medicaments by piercing the septum with a needle connected to a syringe or secondary tubing set. “Y” Injection site with a latex-free polyisoprene septum is available.
Connectors with a rotating Luer-Lock thread are especially easy to seal.
A connection to the IV catheter can be made safely with lockable connectors.
An infusion set can be completed with an intravenous needle and a Luer-Slip adapter.
An intravenous needle with the standard bevel for universal application.
